輸入頻率(Input Frequency) |
3.4 to 4.2Ghz |
|
本振頻率(L.O. Frequency) |
5150MHz(±500 MHz@25℃) |
|
輸出頻率(Output Frequency) |
950-1750MHz |
|
輸入端本振泄漏(L.O. Leakage Input Port) |
45dBm |
|
本振穩(wěn)定度(L.O. Stability) |
±1.5MHz(-40℃to+70℃) |
|
噪聲系數(shù)(Noise Figure) |
<17°K typ |
|
增益(Conversion Gain) |
>65dB typ |
|
增益平坦度(Gain Flatness) |
±1 dBm(max) |
|
輸入駐波(Intput VSWR) |
2.5:1(max) |
|
輸出駐波(Output VSWR) |
2.0:1(max) |
|
輸出連接(Output Connector) |
F-female Connector |
|
輸出阻抗(Output Impedance) |
75Ω |
|
極化隔離(Cross Polar Isolation) |
20dB(min) |
|
鏡頻抑制(Image Rejection) |
45 dB (min) |
|
相位噪聲(Phase Noise) |
-75dBc/Hz@10kHz(max) |
|
供電電壓(Supply Voltage) |
1)11.5-14.0v(Vertical Polarization) , 2)16.0-19.0v(Horizontal Polarization) |
|
工作溫度(Operating Temperature) |
-40℃to+70℃ |
|
儲藏溫度(Storage Temperature) |
-40℃to+80℃ |
|
相對濕度(Relative Humidity) |
0%-95% |
